Search for Crane Part number

(click on image to open PDF document)

Figures in which the part appears:
6245101149 (Grove RT 540E )
Also known as:
7576134397, 07576134397, 007576134397
Parts for Grove RT 540E, Figure 6245101149:
Part Number 7576134397: KIT- FRONT WIPER
Pos nr Part number Description Weight in kg
9576101074 KEY, SET P 0.190
7348000669 BRACKET 0.001
9581100048 BULB 0.008
9581100058 LENS 0.050
9581100459 BULB, 12V.
1 6245101145 CAB WELD
2 6705170886 PLATE, MOUNTING 0.660
3 6705012439 PLATE, MOUNTING 0.096
4 7576134398 KIT - SKYLIGHT WIPER 3.620
5 7576134397 KIT- FRONT WIPER 4.210
6 6860100000 SEAL, MODIFIED 0.210
7 6245101061 CHANNEL
8 6245101030 BRACKET, MOUNTING
9 7498100024 GLASS, WINDSHIELD 11.270
10 7498100023 SKYLIGHT WINDOW, CE CONFORMITY
11 7086100002 BLOCK 0.140
12 7086100000 BLOCK, SLIDE 2.525
13 6585100004 CATCH, FRONT LATCH 0.480
14 6245101033 CATCH, REAR LATCH
15 6245101038 CHANNEL, DOOR
16 6245101133 BRACKET, MOUNTING
17 6245101005 MOUNT, STEERING COLUMN
18 6245101004 SUPPORT, CONSOLE
19 6245101002 MOUNT, BRACKET LEVEL
20 6245101036 JAMB, REAR DOOR
21 7498000897 WINDOW ASSEMBLY - REAR
22 7498100028 WINDOW ASSEMBLY - RIGHT HAND
23 7498100026 GLASS, LEFT REAR
24 7498100025 GLASS, SLIDING DOOR 7.316
25 7498100027 GLASS, LEFT FRONT 2.272
26 8496900043 MOULDING 3.440
27 6829015131 SEALANT, ADHESIVE 0.430
28 7511100046 HANDRAIL, GRAB
29 7511001140 HANDRAIL, GRAB 3.402
30 7511001139 HANDRAIL, GRAB 2.270
31 7511100048 HANDRAIL GRAB
32 7511100047 HANDRAIL, GRAB
33 7511001255 HANDLE; GRAB 2
34 7126211150 CAP SCREW, M12 X 20MM HEX HEAD
35 7628000025 MIRROR ROUND 0.80
36 7184001014 BRACKET, MIRROR ARM 0.64
37 7949001149 FITTING, WASHER NOZZLE 0.160
38 6705100026 PLATE, MOUNTING 0.360
39 6245101034 ANGLE
40 7425100015 FAN ASSEMBLY - 12 VOLT CAB 1.95
41 8496980002 MOULDING 9
42 7581100044 LIGHT ASSY - WORK 12 VOLT
43 7581000186 LIGHT, DOME 0.175
44 7576000320 PUMP AND CANISTER 0.770
45 9543100045 HOSE (25 0.460
46 7486000225 LEVEL, CIRCULAR 1.25
47 7025100013 HORN 0.400
48 7348000667 EXTINGUISHER, FIRE 5
49 6705016902 PLATE, COVER 0.090
50 6245101104 PLATE, COVER
51 7850000046 STRAP, GROUND 0.124
52 7511000161 HANDLE, TAPERED 0.086
53 7585000720 HANDLE, LATCH 0.400
54 6608001308 LUG
55 7834100003 SPRING 0.072
56 6511100009 HANDLE, DOOR (MODIFIED) 1.040
57 6810002810 SHAFT 0.900
58 7069001045 BEARING 0.005
59 7115160750 CAPSCREW 0.018
60 7949000623 WASHER, BLACK PLASTIC 0.005
61 7115182250 CAPSCREW 0.080
62 7660141601 LOCKNUT, HEX 0.004
63 7392100011 PANEL, INNER DOOR
64 7659000796 NUT 0.018
65 7069000516 BEARING 0.113
66 7111161264 BOLT, CARRIAGE 0.110
67 7951190014 FLATWASHER 1OMM I.D. 0.005
68 6245101144 DOOR WELDMENT, CAB
69 7790100871 SCREW 0.001
70 7790140853 SCREW, SELF-TAPPING 0.006
71 6705100083 PLATE, TAP 0.050
72 6245101009 PLATE, RIGHT HAND CONSOLE
73 6245100273 BAR, LATCH 0.140
74 7506000001 GROMMET 0.005
75 7950180141 FLATWASHER 1/2" I.D. 0.009
76 7115140650 BOLT, HEX 1/4"-20 HC X 3/9 - GPO S 0.036
77 7105140650 CAPSCREW, 0.008
78 7951150210 LOCKWASHER 6MM I.D. 0.16
79 7790100853 SCREW, SELF-TAPPING 0.100
80 7126171250 CAP SCREW, M8X25 HEX HEAD
81 7951170210 LOCKWASHER 8 MM 0.002
82 7126211353 CAP SCREW, M12 X 30MM HEX HEAD 0.045
83 7951210210 LOCKWASHER 12MM I.D. 0.004
84 7126151650 CAP SCREW, M6 X 45MM HEX HEAD
85 7661150003 6 MM DIA NORM 0.008
86 7951150014 WASHER 6MM I.D. 0.010
87 7126191750 CAP SCREW, ML X 50MM HEX HEAD
88 7951190210 LOCKWASHER 10MM 0.005
89 7661190003 NUT, HEX 0.011
90 7126191450 CAP SCREW, MIO X 35MM HEX HEAD
91 7126191153 CAP SCREW, M10 X 20MM HEX HEAD
92 7660160000 NUT, HEX 0.018
93 7111161064 BOLT, CARRIAGE 0.024
94 8496900046 MOULDING 0.548
95 7951170014 WASHER, 8MM I.D. FLAT 0.050
